How to Build a Webflow Burger Menu with Animations

How to build a Webflow burger menu with animations

How to build a Webflow burger menu with animations

What you'll learn

How to setup a burger menu

How to animate the slide in of a menu bar in Webflow

Transcript

hello YouTube gang and welcome to the

first design direction of 2020 sorry

it's taken me some time to put some

stuff together

things have been coming in thick and

fast and you know I've got quite a lot

good news coming in obviously the the

nomination for Best independent by aw

Awards didn't actually make the cut but

just to get nominated was you know was a

surprise and also a great great

treatment to start off with and as well

as being made one of the jury members at

AAW Awards again something that I didn't

ever everything was possible but you

know great and really happy with that

and things that are in the pipeline some

of you may have seen or heard I am

potentially working on a master class

and the level that I want to go in with

this master class is going to be quite

in-depth with all the other things that

are going on I am struggling to find

time to do that as well in as well as

videos in for you guys as well so it's

coming I don't know when I really give

you I can't really give you the final

answer but just stay tuned hopefully

I'll be able to pull my finger out and

then and start to put this together but

it's in the process

today's lesson is gonna be pretty

straightforward I guess I mean quite a

few people asked about how you create

burger menus and some of the things you

can do this is just kind of gonna be me

exploring think about things playing

around with some ideas and this just see

where it goes and see what we come out

with and that's pretty much it so let's

jump straight into wit flow so now we're

in web flow let's just have a little

think about what is currently available

to us in web flow now obviously in the

panel you know we do have a navigation

which is there and it's not something

that I've used I don't think ever and

all of my navigations I do I build out

from scratch and it would be exactly the

same process with the burger menu so

let's kind of get straight into it and

what we're going to do is we go through

I'm just going to be kind of giving you

my full processes how we could we file

were advanced different elements to the

menu so what I'm going to do is I'm

going to drop in a first day and I'm

going to call this menu parents and

we're going to make this by 50 pixels by

50 pixels as you can see over here it's

all right corner

aren't you going to put this to fixed

and I'm just going to move it over at

left corner sorry well now I'm going to

move it over to my right corner and I'm

going to do 40 pixels and I'm going to

do 40 pixels

I can't currently see it right now and

so I'm gonna back up on this just so we

can see it for the purpose of this of

this demo and then I'm gonna put it on

flicks and I'm going to put it on center

center so now we've got the button area

something to think about as well

especially when you're doing burger menu

just think about that hit area that is

really important I think the guidelines

the standard guidelines is around 4045

pixels that that hip area should be

especially when you get down into mobile

devices I mean a small hip area is gonna

be tricky

for them fingers so now we've got that

menu parent let's just drop in another

div and we're gonna call this menu and

I'm going to do a width of 20 pixels and

I'm gonna I do a height of 2 pixels and

then I'm going to give it a background

color so now we've got that line little

bar in there we can pretty much just

apple see Apple V Apple see Apple B now

currently we have a line so it's very

straightforward its back to the parent

and that is because I need to change the

directions of vertical and now we have

them all sitting underneath other but we

need to put a little bit of margin on

these so I'm probably gonna put

four pixels now if we look at this it

doesn't look in the center so we're

gonna have to get back to the parent

just make a padding adjustment again by

four pixels and now we're in the middle

we're looking good that's that's the

button done relatively quickly great

going into the overlay now we're just

going to get another div we're not going

to do it in this parent this is going to

be separate and one other thing just to

think about cuz I forgot that on the

menu parent we just want to make sure

that the z-index is to the top of the

page because we always want that button

to be the highest element on the page

especially when you've got other

elements below we want to make sure that

that is and then with this we're going

to call this menu overlay so now we have

the menu over they we're going to do

pretty much the same prints cause what

we did last time we're going to do a

width 100% we'll do a height behind

review point iron we're going to put

this on fixed again because we want it

to be fixed to wherever we open this up

on the page and then we can just go

underneath that button so nine nine

eight so we know that it's bang

underneath that bar but then it's going

to be again on top of all of them

elements which we want

I'm going to give it a background color

of course probably not black let's just

touch that light a little bit more and

now we have this menu overlay now little

bit of a tip some of you may know it

some of you might may not know it took

me ages but I stumbled across it another

art that's that's how you do it so when

you put any positions on a fixed or

absolute and you start to animate by the

size you can actually control the

direction of that movement so here we

have a pin to the left so if I pin that

to the left and I did a size it would go

from left to right if I pinned it to the

right go right

it's a left if I dumb it from the bottom

it would go bottom to top if I did it

from the top it'd go top to bottom so

that's a really good thing to remember

if you want animations that coming from

different directions by size obviously

by movement you can move them any

direction it's all good but if you're

trying to do this size movement which is

a different kind of animation style to a

move move I guess more of a more of a

rigid movement where size is kind of

it's kind of a little bit more of a yeah

open and close communism that's

something to think about when you when

you're animating properties on size so

now we've got the menu overlay in we're

going to put this on flex as well

I'm not going to do sense Center because

I kind of want this to the side a little

bit and I'm what I'm going to do is I'm

going to call this nav link parent and

what I'm going to do is I'm probably

just going to give it 120 pixels we want

it to be 120 pixels off the side now

we've got this what we can do is we can

drop in a list now there's many ways

that you could pretend to build a

navigation I always use lists kind of

traditional but that's the way that I

like to build them we had the lists

which is in here and then we have our

list item and then what we can do with

that list item is we can drop a link in

and then we can call this nav link we

can size it and I'm going to use

viewpoint width again something that are

like as you know and we're gonna have to

use the height so we'll have to put the

high on and just go 105 and we're going

to change this font we're going to go

and use that font we've used before make

sure it's on the right weight and then

we're going to change it to white now

what I'm going to do now is I'm going to

you some very generic own other hats and

contact so now we have that in let's

just have a quick look at it

noise okay I think we could essentially

make the heights a bit bigger it still

feels like it needs a bit more spacing

in between each of the words and again

just a note why I use % % just seems to

keep the ratio really well when you

start to scale things down you can pump

this up to nine yeah I think I think

eight actually it's just me

krasin eight you know right boom great

that's that's perfect so now we've got

kind of a base structure of what what

we're looking for

now let's bear in mind on on what this

is it's a nav so a good little rule of

thumb make sure we change the tag to

math now again it's changed the icon up

here and we now know that this isn't

that so now we've got this structure and

there's obviously other things you could

potentially add inside and snap you

could have you know images could be

social linked could be all sorts of

stuff now a standard kind of approach

this would be well let's let's this

actually do it an approach would be like

okay go to a mouse click I'm gonna do

menu menu click and I'm going to grab my

overlay and I'm just gonna go yeah I'm

gonna set this on the initial state then

move it up and I'm gonna move it down to

0% which you know it's you know it's

kind of standard we changed these ins we

can play around with the timings a

little bit still you know it's pretty

linear it's pretty boring I'm not really

seeing any any pushing on it let's split

push so the things that we can do with

this and let's just start thinking about

the introduction of elements and really

helps bring down animation

forward so we've got these links and I

think staging them links him could be a

great way of bringing this to life so

let's just get rid of this that was just

to show you what you could potentially

start off with and now we're going to

move into what we can do with it so

we've got this nav link and what we want

to do it isn't having if we want to give

it a combo class now the reason that we

want to give it a combo class is that

when we go to target by a class it means

that when I copy this and drop it onto

another page it's still gonna read them

links and if you do it by selected and

I've seen things break because the

selected element is literally selected

by the page and you want a hard hard

make this in if anything so I'm going to

give this one first second and then

third so now we have that and go back to

our bottom do the menu flick you can now

start to play around with this now I'm

going to move this one I'm gonna go and

move and I'm going to move it down a

hundred percent now just to let you know

the list item has an overflow hidden to

this list I'm gonna move and unless you

can't see it so now we're gonna set that

to the initial so that's the initial

hurry up and we're going to do a move

zero and I'm kind of want to move with

this really like fluid and loop so let's

again remember I said play around with

these different animation types I'm

going to go for out Quint and I'm gonna

really slow it down so it feels look at

that look at that movement is just and

when you start to pair this up we can do

quick way and do a duplicate and then

when you do a duplicate I'm going to

select both of these change target on to

that second one and all we need to do is

just pump that onto that one pump that

onto that one and then

just change the delay on it and I find

this quite a nice way of doing it so I

just do duplicate the first and I

duplicate the ends I select both of them

I change and then I change the link

again just go in there change target and

then select that target and then all I

have to do now is just move them back on

to the relative places that they need to

go that's an initial stay and that's my

end state but again I need to put a bit

of timing on that and if we have a look

beautiful works really nicely already so

we're starting to move through this now

I'm thinking I don't want to do a move

I've got to move

we probably got to move a million times

let's do something more interesting at

least as I said earlier about that size

property let's do that now I want this

now to come up from the bottom I want

it's cut from the bottom and I just just

been presented it in a different way

this is try it and see what this looks

like so I'm going to go back to the

button I'm going to click the bar I'm

going to go like this I'm gonna go to

here I'm going to go size width or make

sure that you plug all of these

measurements in when you're doing

interactions now some people might leave

this blank because it's defined on the

page and again through experience I've

found sometimes that it doesn't register

and it affects it affects the way that

it may respond responsively now I

haven't got an example to show you how

that works but just go right it is a

hundred percent width and the height is

zero you went height and what I want to

do now is go to the end of that size

when they go width and received no

height hundred you point right now what

we want to do is we're gonna have to

adjust these timings now because we need

this to have a bit of time

I'm gonna I'm going to put it onto the

court was what we had for the size and

I'm going to do a 1.5 and I'm probably

just going to move these along so let's

go I recommend that one a eight this one

let's see

and this 10.4 so when we look at the

movement you see the difference or where

they let's just there's the difference

in that movement it's just so much

different and we can make it even

further we push it even further and with

difference and this is the reason why

you might want to use the side property

that only links coming too early for me

so again we're just gonna tweak and

adjust eight six great love it

now we could create a bit of a dynamic

movement on this goes up link to come

down let's try that because that could

be quite nice so let's just put these

two - - and - let's have a quick look

boom let's try that again yeah it's nice

I think what we should do is probably

just speed that up a touch one two three

beautiful I still think these need to be

a little bit long like little bit slower

like in terms of the delay of it and

feel like they just that movement kind

of gets to Easter kind of - - together

just needs a tiny bit of separation to

help that breathe beautiful love it

great so now we've got that animation

how do we push this further so if we go

to the to the menu parent and we're

going to do one thing here we're going

to choose an image obviously you know

the goonies project that I worked on and

the little Gainey's picture we all love

a bit ago unions don't we and then what

I'm going to do is I'm going to add an

overlay on this just because it is a

little bit strong and then

once you see what happens when you add

an image to this it's quite staggering

so we see that movement now you see how

that kind of opens up is it's great it

works really really well let's just have

another look beautiful right so now

we've got that built we've you know

we've gone through that process we've

really started to push it there's

obviously a lot more things that we

could do with this and that's just a

starting point to think about how you

can advance and move things forward now

one little thing that we need to just do

quickly here is do the second click and

one other thing that we need to think

about is this menu overlay now this menu

overlay potentially could be overlaying

your content which means you're not

going to be able to link Tech cetera etc

so do this get into doing a habit of

this initial state is hidden and then

what we want to do is the hide and choke

we want to show it back there straight

away so now that it won't be affecting

any of your page when you click it it

will transition and then all we need to

do is go here we need to duplicate this

I need to click this we now can just

reverse this back so we know we're in -

100 - 100 - 100 we know that that's

going to be a hired and the size is

going to be to zero and now that's done

we can get rid of all them Enosh initial

interactions that we did from the

duplication of the first click and then

all we need to do is just work out the

timings so for me I think let's go that

on zero that on point two and that on

point for this needs to go right at the

end so this it needs to be right out of

the way of of them animation and then

it's just go not eight and let's just

have a quick look boom

all that that in well that great did it

and I don't know why I didn't go up so

let's just

queeny's up and it's just it's a speed

that up on that one doesn't need to be

as slow on the way out that is strange

that's why it's on the pixels so let's

just go back sorry it should be on

percent and that now will hide them

links just this one in in two two two

beautiful and there you go I mean that

is quite a quick process but see how we

gradually just progressed it you know

ideas right now obviously we can animate

the burger menu you could potentially

make this a magnetic further menu so

when you go to it moves towards your

mouse you could bring the image in as a

different div and then you could do a

bit of a parallax movement on it there's

so many different possibilities you can

do and just with that simple process of

going from and thinking about how you

can change and the animation now you can

change them types of animations can

really go from something that's quite

linear and quite boring to something

that looks pretty snazzy so guys don't

forget if you like this tutorial please

give it a thumbs up and subscribe and

I'll see you around and I'll see you

soon

cheers guys
